ORTUR 20000mm/min fast Laser Engraver Laser Master 3 10W Output Power Laser Engraving Cutting Machine for DIY Metal Wood


Model Number: OLM3-LU2-10A-US
Power: 10W
Precio:
$ 19,295.82
Stock:
Pronto en stock

Descripción

Products Description
TURE 10W OUTPUT POWER:
This ORTUR laser engraver equipped with TRUE 10W laser module, which is able to cut 20mm wooden boards and 30mm acrylic sheets. Cut through 10mm pine board one pass. It is almost beyond the effect of 60W CO2 laser.
MUCH MORE POWERFUL ENGRAVING EFFECT
The 3rd Beam Combining Technology with Double Compression Spots of the new laser can work very well at high speed of 20000mm/mm, save you over half time than other similar brands.
High-power and lightweight 10W laser module
10W Upgraded Laser Module - The focusing spot area of the new laser is only 1/3 of other ordinary lasers and Integrated Air Assist/Dual Fans/Foldable Focal Gauge/All in 235g Weight. Combine precision engraving and high energy cutting at the same time. It can work very well at high speed of 20000mm/mm, save you over half time than other similar brands.
Totally User Friendly Laser Engraver
It supports SD Card/USB/Wi-Fi APP/Access Point Offline Work. Professional APP- Laser Explorer, Easy to Use/Automatic Operation Guide/Novice Friendly, is compatible with iPhone, Android Phones, iPad and Android Pad. Drag the NC file to the SD card, the machine starts working, and then you can turn off the computer or mobile phone without worrying about disconnecting, which is more convenient to print for a long time. No computer restrictions, engraving work anytime, anywhere.
7 SAFETY PROTECTION SYSTEMS:
Security Lock (Keep the Key,Professional Use Only), Active Position Protection, Sloping Position Protection, Exposure Duration Detection and Limitation, Voltage and Current Safety Control System, Host Computer Watchdog, Emergency Stop Switch.

SD CARD SLOT

Drag the NC file to the SD card, the machine starts working, and then you can turn off the computer or mobile phone without worrying about disconnecting, which is more convenient to print for a long time.

YRR TRANSFER SWITCH

There is no need to use the Y-axis motor cable to insert the YRR, and you can switch between the YRR and the Y-axis motor with a flick of a switch.

TMC2209 SILENT -STEP MOTOR

Supports any corner of the infinite switch to return to position, the driving current and resolution can be adjusted, and the protection is blocked.
Product Parameter
Engraving Area : X400*Y400mm
Engraving Speed : O-2000Omm/min
Gross Weight : 6.5KGS
Warranty: 12 Months
Machine Size: 580*550*150mm
Laser Wavelength : 455+-15nm
Spot Size : About 0.05*0.1mm
Motors : 42x60Y Stepper Motor x1\42x40X Stepper Motor x1
Motherboard : OLM-ESP-PRO-V2.4
Product material : 70%Aluminum + 15% Steel + 5% Plastic + 5% Brass + 5% Others
Available Luminous Power: LU2-10A (9500-10500mw)
File Format : JPG/JPEG /PNG /BMP / SVG / ETC
Control Software :LaserGRBL /LightBurn /Laser Explorer ( Ortur APP)
